C32 IGBT Buffer Capacitor

Technical Parameter

Reference Standards

IEC61071, GB/T17702

Operating Temperature Range

-40℃~ +70℃

Capacity Range

0.1uF ~5.0uF

Rated Voltage

700VDC~3000VDC

Capacity Tolerance

±5%(J); ±10%(K)

Withstand voltage

1.5Ur DC/10S

Dissipation Factor

tgδ≤0.0005 C≤1μF f=10KHz at 20℃
tgδ≤0.0010 C≥1μF f=10KHz at 20℃

Insulation Resistance

C≤0.33μF Rs≥30000MΩ (at20℃ 100VDC 60S)
C>0.33μF RsC≥100000S (at20℃ 100VDC 60S)

Flame Retardation

UL94V-0

Life Expectancy

100000hrs ( Ur hotspot ≤ 85℃)


●  IGBT Snubber circuit, IGBT Snubber equipment.

● Widely used in power electronic equipment like UPS, inverter, induction heater, absorption protection of peak voltage and peak current for welding machine and other equipment.


●  PET tape wrapping, epoxy resin sealing

●  Axial leads with tinned copper wire

●  High voltage, small tgδ, low temperature rise

●  Low ESL and ESR

●  High pulse current, high dV/dt
